Tonzi: 2019-10-24 11:00:00 (DOY 297)
Author: Joe Verfaillie
Others: Siyan

Summary: Standard fieldwork, trees turning brown, Tested two tipping buckets, took black body images with FLIR

Tonzi
2019-10-24

Siyan and I arrived at 11:00. It was clear, sunny and mild with little to no wind. Things are very dry and the trees are turning brown but still some water in the pond.

Siyan did the soil moisture, wells, DBH, serviced the z-cams and collected data from the isolated data loggers.

I collected the data from the eddy systems and tower computer.

I tested two of the four the tipping buckets at Tonzi. I added a pluggable screw terminals to the wires to make it easier to disconnect from the data loggers and plug into the calibration CR23x. After connecting the bucket to the CR23x, I dripped 475ml of water through the bucket which should result in 100tips.
Tipping bucket sn 24872-999 at the soil co2 got 100 tips.
Tipping bucket sn 48130-611 at OSU SP1 got 104 tips. I did not adjust either one.

I also took two photos of the black body temperature sensor with the FLIR. One at 30.6C and one at 40.7C. This is possible for one person by hanging the black body on a pole in front of the camera and using a laptop with the FLIR wget command.

Field Data

No tank data

Well Depth

Date	Location	Depth (feet)
2019-10-24	VR_well	58.8
2019-10-24	TZ_floor	27.3
2019-10-24	TZ_tower	32.1
2019-10-24	TZ_road	36.4
2019-10-24	VR_pond	13.98

mode = both
Moisture Point Probes TZ
Array ( [0] => Tower_1 [1] => Floor_South_1 [2] => Floor_West_1 [3] => Soil_Transect_4_1 [4] => Soil_Transect_3_1 [5] => Soil_Transect_2_1 [6] => Soil_Transect_1_1 [7] => SoilCO2_West_A_1 [8] => SoilCO2_West_B_1 [9] => SoilCO2_West_C_1 [10] => Tower_2 [11] => Floor_South_2 [12] => Floor_West_2 [13] => Soil_Transect_4_2 [14] => Soil_Transect_3_2 [15] => Soil_Transect_2_2 [16] => Soil_Transect_1_2 [17] => SoilCO2_West_A_2 [18] => SoilCO2_West_B_2 [19] => SoilCO2_West_C_2 [20] => Tower_3 [21] => Floor_South_3 [22] => Soil_Transect_4_3 [23] => Soil_Transect_3_3 [24] => Soil_Transect_2_3 [25] => Soil_Transect_1_3 [26] => SoilCO2_West_A_3 [27] => SoilCO2_West_B_3 [28] => SoilCO2_West_C_3 [29] => Tower_4 [30] => Soil_Transect_4_4 [31] => Soil_Transect_3_4 [32] => Soil_Transect_2_4 [33] => Soil_Transect_1_4 [34] => SoilCO2_West_A_4 [35] => SoilCO2_West_B_4 [36] => SoilCO2_West_C_4 )

0000

Date	DOY	Rep	Depth	Tower_1	Floor_South_1	Floor_West_1	Soil_Transect_4_1	Soil_Transect_3_1	Soil_Transect_2_1	Soil_Transect_1_1	SoilCO2_West_A_1	SoilCO2_West_B_1	SoilCO2_West_C_1	Tower_2	Floor_South_2	Floor_West_2	Soil_Transect_4_2	Soil_Transect_3_2	Soil_Transect_2_2	Soil_Transect_1_2	SoilCO2_West_A_2	SoilCO2_West_B_2	SoilCO2_West_C_2	Tower_3	Floor_South_3	Soil_Transect_4_3	Soil_Transect_3_3	Soil_Transect_2_3	Soil_Transect_1_3	SoilCO2_West_A_3	SoilCO2_West_B_3	SoilCO2_West_C_3	Tower_4	Soil_Transect_4_4	Soil_Transect_3_4	Soil_Transect_2_4	Soil_Transect_1_4	SoilCO2_West_A_4	SoilCO2_West_B_4	SoilCO2_West_C_4	Spacial Count
2019-10-24	297	0	nan	4.2	5.3	5.9	1.5	2.7	3.6	0.4	0.1	5.9	2.5	10.6	4.8	5.4	8.7	142	11.5	4	8.7	0.6	12.4	13.7	8.4	9.2	12	15.5	13.4	16.8	14.8	12	17	10.5	16.8	24	11.3	14.8	17.3	23.7
2019-10-24	297	1	nan	4.7	6.2	3.8	0.6	4.5	3.6	0.4	5.9	6.5	1	11.2	4.8	6.9	7.5	14.5	10.9	4.5	8.7	0.2	11.8	13.7	8.4	9.5	12	16.2	12.9	16.8	14.8	12.3	17	11.3	16.5	25.4	11.6	14.8	17	22.8
2019-10-24	297	Avg	0-15cm																																						0
2019-10-24	297	Avg	15-30cm																																						0
2019-10-24	297	Avg	30-45cm																																						0
2019-10-24	297	Avg	45-60cm																																						0

mode = both
Moisture Point Probes VR
Array ( [0] => Solar_Panels_1 [1] => Flux_Tower_1 [2] => Biomass_Cage_1 [3] => Solar_Panels_2 [4] => Flux_Tower_2 [5] => Biomass_Cage_2 [6] => Solar_Panels_3 [7] => Flux_Tower_3 [8] => Biomass_Cage_3 [9] => Solar_Panels_4 [10] => Flux_Tower_4 [11] => Biomass_Cage_4 )

0000

Date	DOY	Rep	Depth	Solar_Panels_1	Flux_Tower_1	Biomass_Cage_1	Solar_Panels_2	Flux_Tower_2	Biomass_Cage_2	Solar_Panels_3	Flux_Tower_3	Biomass_Cage_3	Solar_Panels_4	Flux_Tower_4	Biomass_Cage_4	Spacial Count
2019-10-24	297	0	nan	3.9	1.5	1.2	13	12.4	7.5	16.5	7.3	16.5	28.2	16.2	19.9
2019-10-24	297	1	nan	3.9	3.3	0.9	11.5	12.4	6.6	16.2	7.3	17	28.8	16.2	19.3
2019-10-24	297	Avg	0-15cm													0
2019-10-24	297	Avg	15-30cm													0
2019-10-24	297	Avg	30-45cm													0
2019-10-24	297	Avg	45-60cm													0

No TZ grass heigth found

No VR grass heigth found

Tree DBH

Date	Tag#	Reading (mm)
2019-10-24	1	19.2
2019-10-24	102	9.1
2019-10-24	2	12.9
2019-10-24	245	10.3
2019-10-24	3	18.8
2019-10-24	4	5.0
2019-10-24	5	15.4
2019-10-24	7	19.0
2019-10-24	72	3.7
2019-10-24	79	15.9
2019-10-24	8	7.2
