Field Notes

<--2018-08-10 09:15:00 | 2018-09-13 13:20:00-->
Other sites visited today: Tonzi
Phenocam link: Searching...

Vaira: 2018-08-30 13:00:00 (DOY 242)
Author: Joe Verfaillie
Others: Siyan

Summary: Vairas and others out to look at the fire damage, quick data collection, mild weather.

Vaira
2018-08-30

Siyan and I arrived at about 9:45. Jim and Dale Vaira were at the gate with other local ranchers and land owners â€“ a handful of big trucks and trailers. They were there to assess the damage to fences and pasture caused by the fire. Jim said about 60 to 80 acers of their land burned. They hoped to get some reimbursement for their loss. Due to the traffic we went to Tonzi first and came back about 1pm. At that time most of the crew were parked near our site and were headed out.

The weather was very mild for this time of year. Patchy clouds were coming in from the southeast and there was a strong cool breeze blowing. It felt like tropical moisture. The ground is still very dry, the water hole is empty and the trees are senescing. We did not go to the pond.

We quickly collected data and headed home. No problems found. We did not do spectral due the variable light conditions.

Field Data

No tank data

Well Depth

Date	Location	Depth (feet)
2018-08-30	TZ_floor	25.7
2018-08-30	TZ_tower	30.2
2018-08-30	TZ_road	34.8

mode = both
Moisture Point Probes TZ
Array ( [0] => Tower_1 [1] => Floor_South_1 [2] => Floor_West_1 [3] => Soil_Transect_4_1 [4] => Soil_Transect_3_1 [5] => Soil_Transect_2_1 [6] => Soil_Transect_1_1 [7] => SoilCO2_West_A_1 [8] => SoilCO2_West_B_1 [9] => SoilCO2_West_C_1 [10] => Tower_2 [11] => Floor_South_2 [12] => Floor_West_2 [13] => Soil_Transect_4_2 [14] => Soil_Transect_3_2 [15] => Soil_Transect_2_2 [16] => Soil_Transect_1_2 [17] => SoilCO2_West_A_2 [18] => SoilCO2_West_B_2 [19] => SoilCO2_West_C_2 [20] => Tower_3 [21] => Floor_South_3 [22] => Floor_West_3 [23] => Soil_Transect_4_3 [24] => Soil_Transect_3_3 [25] => Soil_Transect_2_3 [26] => Soil_Transect_1_3 [27] => SoilCO2_West_A_3 [28] => SoilCO2_West_B_3 [29] => SoilCO2_West_C_3 [30] => Tower_4 [31] => Floor_South_4 [32] => Soil_Transect_4_4 [33] => Soil_Transect_3_4 [34] => Soil_Transect_2_4 [35] => Soil_Transect_1_4 [36] => SoilCO2_West_A_4 [37] => SoilCO2_West_B_4 [38] => SoilCO2_West_C_4 )

0000

Date	DOY	Rep	Depth	Tower_1	Floor_South_1	Floor_West_1	Soil_Transect_4_1	Soil_Transect_3_1	Soil_Transect_2_1	Soil_Transect_1_1	SoilCO2_West_A_1	SoilCO2_West_B_1	SoilCO2_West_C_1	Tower_2	Floor_South_2	Floor_West_2	Soil_Transect_4_2	Soil_Transect_3_2	Soil_Transect_2_2	Soil_Transect_1_2	SoilCO2_West_A_2	SoilCO2_West_B_2	SoilCO2_West_C_2	Tower_3	Floor_South_3	Floor_West_3	Soil_Transect_4_3	Soil_Transect_3_3	Soil_Transect_2_3	Soil_Transect_1_3	SoilCO2_West_A_3	SoilCO2_West_B_3	SoilCO2_West_C_3	Tower_4	Floor_South_4	Soil_Transect_4_4	Soil_Transect_3_4	Soil_Transect_2_4	Soil_Transect_1_4	SoilCO2_West_A_4	SoilCO2_West_B_4	SoilCO2_West_C_4	Spacial Count
2018-08-30	242	0	nan	2.7	0.1	3.5	9.2	0.9	2.7	1.3	3.9	7.4	1.8	10.9	9.7	5.7	7.4	13.3	11.5	4.2	9.3	0.6	10.6	14	9.8	22.1	9.5	12.6	15.6	14	17	15.7	14	17	3.9	11	17.3	26.8	11.9	17	19.1	21.4
2018-08-30	242	1	nan	3.6	1.2	4.2	1.9	1.8	3	1.3	1.6	7.7	2.1	11.8	9.3	5.1	8.1	13.3	11.2	3.8	8.7	0.5	11.5	14.3	10.3		8.5	12.6	16.5	13.7	16.8	14.3	13.1	17.6	4.7	11.3	17.9	26.2	11.6	17	18.8	23.6
2018-08-30	242	Avg	0-15cm																																								0
2018-08-30	242	Avg	15-30cm																																								0
2018-08-30	242	Avg	30-45cm																																								0
2018-08-30	242	Avg	45-60cm																																								0

mode = both
Moisture Point Probes VR
Array ( [0] => Solar_Panels_1 [1] => Flux_Tower_1 [2] => Gate_1 [3] => Biomass_Cage_1 [4] => Solar_Panels_2 [5] => Flux_Tower_2 [6] => Gate_2 [7] => Biomass_Cage_2 [8] => Solar_Panels_3 [9] => Flux_Tower_3 [10] => Gate_3 [11] => Biomass_Cage_3 [12] => Solar_Panels_4 [13] => Flux_Tower_4 [14] => Gate_4 [15] => Biomass_Cage_4 )

0000

Date	DOY	Rep	Depth	Solar_Panels_1	Flux_Tower_1	Gate_1	Biomass_Cage_1	Solar_Panels_2	Flux_Tower_2	Gate_2	Biomass_Cage_2	Solar_Panels_3	Flux_Tower_3	Gate_3	Biomass_Cage_3	Solar_Panels_4	Flux_Tower_4	Gate_4	Biomass_Cage_4	Spacial Count
2018-08-30	242	0	nan	0.3	1	6.8	0.9	8.1	7.5	4.2	5.4	14.8	6.2	8.1	17	28.5	14.2	21.1	19.6
2018-08-30	242	1	nan	0.6	1	7.1	0.9	7.8	7.2	4.5	5.1	14.3	6.4	8.1	16.5	28.8	14.2	21.1	17.9
2018-08-30	242	Avg	0-15cm																	0
2018-08-30	242	Avg	15-30cm																	0
2018-08-30	242	Avg	30-45cm																	0
2018-08-30	242	Avg	45-60cm																	0
