Field Notes

<--2020-02-27 11:30:00 | 2020-03-12 10:00:00-->
Other sites visited today: Tonzi
Phenocam link: Searching...

Vaira: 2020-03-02 13:15:00 (DOY 62)
Author: Joe Verfaillie
Others:

Summary: Installed an FD Chamber, re-glued phenocam window

Vaira
2020-03-02

I arrived at about 13:15. It was clear sunny and mild with a gusty wind from the WNW. Still no rain and dry. Broadleaf plants seem to be overtaking the grass. There were cows around.

I installed one of the new FD Chambers sn FD20200001. It went in near the eosGP probes to the west. Itâ€™s power from the power plug on the CR10X. This whole box needs to be cleaned up. A 23x could be used which would fix the problems caused by the voltage divider, additionally a couple of the Vaisala transmitter boxes are not used.

I re-glued the phenocam case window. This required moving the camera so there may be a small change in FOV. I checked that the camera was okay by borrowing the Ethernet from the CR1000 to use the computer. I should leave a spare Ethernet cable in the box.

I replaced a number of short electric fence standoffs with the longer ones.

I left at about 14:15.

Field Data

No tank data

No VR Well data found

No TZ Moisture Point data found

No VR Moisture Point data found

No TZ grass heigth found

No VR grass heigth found

No VR Tree DBH found

No water potential data found

No VR Grass Biomass data found

No VR OakLeaves Biomass data found

No VR PineNeedles Biomass data found
