Tonzi: 2019-05-14 09:30:00 (DOY 134)
Author: Joe Verfaillie
Others: Daphne, LBL: Baptiste, Ian, Patrick

Summary: LBL/Mirage Systems ECOSTRESS ground truth survey, Standard fieldwork, reset two dendrometers, road well clock ahead by 10min - reset

Tonzi
2019-05-14

I arrive at 9:30am with Daphne. Baptiste, Patrick and Ian from LBL were waiting for us at the gate. The LBL crew will be making ground measurements to compliment flights by Mirage Systems. It was sunny and mild with some high thin clouds and a ring around the sun. The ground surface it dry and crumbly. The grass is still pretty green and there is more rain coming in the next week starting tomorrow.

The LBL crew surveyed the area roughly covered by SMAP soil moisture locations. They walked an EMI device around, took a bunch of GPS points, took some soil samples and flew a quadcopter with RGB camera for micro topography. There were at least three flights by Mirage Systems. There aircraft carried a Ground Penetrating Synthetic Aperture Radar (GPSAR). Operating from 300-3000 MHz, its Ultra Wide Band (UWB) capability provides both the penetration to image buried targets and the resolution to image surface features. All this work is related to the ECOSTRESS project.

http://www.miragesystems.com/

Daphne and I tried to do all the regular fieldwork.

Tower 7500: 10:05, CO2 416.7, H2O 521, T 15.9, P 99.2, SS 101-103
Floor 7500: 11:00, CO2 416, H2O 513, T 19.6, P 99.3, SS 102-103

I swapped out the keyboard on the LattePanda â€“ the mouse buttons on the old one often did not work. The micro SD card also seem to be having problems sporadically mounting and unmounting. I removed the card and changed the FLIR batch script to not move/rename the images. Next time Iâ€™ll try adding a USB drive for storage. I installed the Licor software v8.5.0 on the LattePanda â€“ now you can see the 7500 status from the bottom of the tower.

Daphne collected the data, serviced the z-cams, and measured the well depths. I did the soil moisture measurements. The probe near the Floor solar panels has broken pins and should be removed. The lower two locations of the â€˜Betweenâ€™ probe read bad â€“ maybe the next probe to die. I read the dendrometers. I reset the bands on trees 102 and 72. At tree 102 the small gauge fell off the dendrometer. It needs to be reattach flush with left end of slider.

The road well clock was 10min ahead â€“ reset to 11:07.

A wire was broken on the Tower fence. I forgot to repair it and did not turn on the fence charger.

We tried to do midday water potential. We got relatively consistent readings but had questions on protocol. Our numbers might have been a little high.

We went to Vaira at about1:45 while the LBL crew finished up. We returned at about 4pm and soon after we all left with the LBL crew stopping at Vaira to do a quick survey there.

Field Data

No tank data

Well Depth

Date	Location	Depth (feet)
2019-05-14	TZ_road	23.05
2019-05-14	TZ_tower	18.07
2019-05-14	TZ_floor	13.63
2019-05-14	VR_well	49.13

mode = both
Moisture Point Probes TZ
Array ( [0] => Tower_1 [1] => Floor_South_1 [2] => Floor_West_1 [3] => Soil_Transect_4_1 [4] => Soil_Transect_2_1 [5] => Soil_Transect_1_1 [6] => SoilCO2_West_A_1 [7] => SoilCO2_West_B_1 [8] => SoilCO2_West_C_1 [9] => Tower_2 [10] => Floor_South_2 [11] => Floor_West_2 [12] => Soil_Transect_4_2 [13] => Soil_Transect_2_2 [14] => Soil_Transect_1_2 [15] => SoilCO2_West_A_2 [16] => SoilCO2_West_B_2 [17] => SoilCO2_West_C_2 [18] => Tower_3 [19] => Floor_South_3 [20] => Floor_West_3 [21] => Soil_Transect_4_3 [22] => Soil_Transect_3_3 [23] => Soil_Transect_2_3 [24] => Soil_Transect_1_3 [25] => SoilCO2_West_A_3 [26] => SoilCO2_West_B_3 [27] => SoilCO2_West_C_3 [28] => Tower_4 [29] => Floor_South_4 [30] => Floor_West_4 [31] => Soil_Transect_4_4 [32] => Soil_Transect_3_4 [33] => Soil_Transect_2_4 [34] => Soil_Transect_1_4 [35] => SoilCO2_West_A_4 [36] => SoilCO2_West_B_4 [37] => SoilCO2_West_C_4 [38] => Soil_Transect_3_1 [39] => Soil_Transect_3_2 )

0000

Date	DOY	Rep	Depth	Tower_1	Floor_South_1	Floor_West_1	Soil_Transect_4_1	Soil_Transect_2_1	Soil_Transect_1_1	SoilCO2_West_A_1	SoilCO2_West_B_1	SoilCO2_West_C_1	Tower_2	Floor_South_2	Floor_West_2	Soil_Transect_4_2	Soil_Transect_2_2	Soil_Transect_1_2	SoilCO2_West_A_2	SoilCO2_West_B_2	SoilCO2_West_C_2	Tower_3	Floor_South_3	Floor_West_3	Soil_Transect_4_3	Soil_Transect_3_3	Soil_Transect_2_3	Soil_Transect_1_3	SoilCO2_West_A_3	SoilCO2_West_B_3	SoilCO2_West_C_3	Tower_4	Floor_South_4	Floor_West_4	Soil_Transect_4_4	Soil_Transect_3_4	Soil_Transect_2_4	Soil_Transect_1_4	SoilCO2_West_A_4	SoilCO2_West_B_4	SoilCO2_West_C_4	Soil_Transect_3_1	Soil_Transect_3_2	Spacial Count
2019-05-14	134	0	nan	7.4	6.8	10.3	2.5	7.1	5	8.8	8	5	16.1	9.7	12.7	10.3	17.6	6.9	13	0.8	15.2	19.8	20.7	39.6	12.9	19.9	22.3	18.7	22.9	18.4	22.1	29.1	28.2	41.1	18.2	30.8	37.7	16.2	32.2	28.5	34.5
2019-05-14	134	1	nan	7.7	7.1	11.1	1.6	6.8	5	8.6	8.3	3.6	15.2	10	13.3	11.2	17.6	6.6	13.3	1.1	14.2	20.4	19.8		13.7	19.8	22.9	19.3	22.3	17.9	22.3	28.8	28.8		17	31.1	38	17	33.7	27.1	34.8	5	16.4
2019-05-14	134	2	nan																							19.8										31.4						5	16.4
2019-05-14	134	Avg	0-15cm																																									0
2019-05-14	134	Avg	15-30cm																																									0
2019-05-14	134	Avg	30-45cm																																									0
2019-05-14	134	Avg	45-60cm																																									0

mode = both
Moisture Point Probes VR
Array ( [0] => Solar_Panels_1 [1] => Flux_Tower_1 [2] => Biomass_Cage_1 [3] => Solar_Panels_2 [4] => Flux_Tower_2 [5] => Biomass_Cage_2 [6] => Solar_Panels_3 [7] => Flux_Tower_3 [8] => Biomass_Cage_3 [9] => Solar_Panels_4 [10] => Flux_Tower_4 [11] => Biomass_Cage_4 )

0000

Date	DOY	Rep	Depth	Solar_Panels_1	Flux_Tower_1	Biomass_Cage_1	Solar_Panels_2	Flux_Tower_2	Biomass_Cage_2	Solar_Panels_3	Flux_Tower_3	Biomass_Cage_3	Solar_Panels_4	Flux_Tower_4	Biomass_Cage_4	Spacial Count
2019-05-14	134	0	nan	2.4	2.7	2.4	11.5	12.1	6.6	18.2	7	17.9	31.7	17.9	19.6
2019-05-14	134	1	nan	2.4	2.7	2.4	11.2	11.8	6.3	17.6	6.7	17.3	31.1	17	19.6
2019-05-14	134	Avg	0-15cm													0
2019-05-14	134	Avg	15-30cm													0
2019-05-14	134	Avg	30-45cm													0
2019-05-14	134	Avg	45-60cm													0

No TZ grass heigth found

No VR grass heigth found

Tree DBH

Date	Tag#	Reading (mm)
2019-05-14	1	15.6
2019-05-14	102	19.7
2019-05-14	102	5.3
2019-05-14	2	15.6
2019-05-14	245	11.9
2019-05-14	3	12.4
2019-05-14	4	4.8
2019-05-14	6	11.7
2019-05-14	7	18.7
2019-05-14	72	20.6
2019-05-14	72	4.0
2019-05-14	79	15.9
2019-05-14	8	7.9

Water Potential - mode: raw

Time	Species	Tree	readings (bar)
2019-05-14 12:33:00	OAK	102	-14.5	-11.5	-16
2019-05-14 12:33:00	OAK	35	-25.5	-25	-24
2019-05-14 13:13:00	PINE	OLD	-17	-22	-26
2019-05-14 13:13:00	PINE	YNG	-20	-22	-30

No TZ Grass Biomass data found

No TZ OakLeaves Biomass data found

No TZ PineNeedles Biomass data found

4 photos found

Nice ring around the sun most of the morning

Pond behind Tonzi's house.

Joe taking plant water potential measurements using the pressure bomb.
