Vaira: 2018-12-19 09:30:00 (DOY 353)
Author: Joe Verfaillie
Others: Dennis, Siyan

Summary: Reset stardot clock, well pipe discovered to southeast.

Vaira
2018-12-19

I arrived at about 9:30 with Dennis and Siyan. It was mild and mostly sunny. The ground is damp with small puddles in the road but the water hole is not filling up very fast. Dennis discovered a well to the southeast of the site. We met Jim on the way out and he said it was drilled long ago when one of Mr. Vairaâ€™s brothers though he might build a house there. We will try measuring the water level there.

Dennis did the soil moisture, Siyan did spectral and I collected the data. The Stardot clock was reporting 2018-04-19 09:58 when I reset it to 2018-12-19 09:55:42.

Field Data

No tank data

Well Depth

Date	Location	Depth (feet)
2018-12-19	TZ_floor	30.1
2018-12-19	TZ_tower	34.7
2018-12-19	TZ_road	38

mode = both
Moisture Point Probes TZ
Array ( [0] => Tower_1 [1] => Floor_South_1 [2] => Floor_West_1 [3] => Soil_Transect_4_1 [4] => Soil_Transect_3_1 [5] => Soil_Transect_2_1 [6] => Soil_Transect_1_1 [7] => SoilCO2_West_A_1 [8] => SoilCO2_West_B_1 [9] => SoilCO2_West_C_1 [10] => Tower_2 [11] => Floor_South_2 [12] => Floor_West_2 [13] => Soil_Transect_4_2 [14] => Soil_Transect_3_2 [15] => Soil_Transect_2_2 [16] => Soil_Transect_1_2 [17] => SoilCO2_West_A_2 [18] => SoilCO2_West_B_2 [19] => SoilCO2_West_C_2 [20] => Tower_3 [21] => Floor_South_3 [22] => Floor_West_3 [23] => Soil_Transect_4_3 [24] => Soil_Transect_3_3 [25] => Soil_Transect_2_3 [26] => Soil_Transect_1_3 [27] => SoilCO2_West_A_3 [28] => SoilCO2_West_B_3 [29] => SoilCO2_West_C_3 [30] => Tower_4 [31] => Floor_South_4 [32] => Floor_West_4 [33] => Soil_Transect_4_4 [34] => Soil_Transect_3_4 [35] => Soil_Transect_2_4 [36] => Soil_Transect_1_4 [37] => SoilCO2_West_A_4 [38] => SoilCO2_West_B_4 [39] => SoilCO2_West_C_4 )

0000

Date	DOY	Rep	Depth	Tower_1	Floor_South_1	Floor_West_1	Soil_Transect_4_1	Soil_Transect_3_1	Soil_Transect_2_1	Soil_Transect_1_1	SoilCO2_West_A_1	SoilCO2_West_B_1	SoilCO2_West_C_1	Tower_2	Floor_South_2	Floor_West_2	Soil_Transect_4_2	Soil_Transect_3_2	Soil_Transect_2_2	Soil_Transect_1_2	SoilCO2_West_A_2	SoilCO2_West_B_2	SoilCO2_West_C_2	Tower_3	Floor_South_3	Floor_West_3	Soil_Transect_4_3	Soil_Transect_3_3	Soil_Transect_2_3	Soil_Transect_1_3	SoilCO2_West_A_3	SoilCO2_West_B_3	SoilCO2_West_C_3	Tower_4	Floor_South_4	Floor_West_4	Soil_Transect_4_4	Soil_Transect_3_4	Soil_Transect_2_4	Soil_Transect_1_4	SoilCO2_West_A_4	SoilCO2_West_B_4	SoilCO2_West_C_4	Spacial Count
2018-12-19	353	0	nan	27.3	21.7	24.1	15.3	21.2	19.4	13.6	29.1	31.7	15	24.6	29.2	29.2	24	31	31.3	12.1	27.7	17	29.8	19.3	36	39.6	22.9	29.9	31	21.2	35.2	33.2	37.4	16.5	6.4	31.9	17.9	42.8	34	11.6	39.4	48.3	34.8
2018-12-19	353	1	nan	26.7	11.1	24.4	14.7	20.6	20.3	13.5	29.4	30.5	14.4	24	29.2	28.9	23.7	31.3	31.3	12.4	25.2	16.4	29.8	18.7	35.7	32.4	22.3	30.1	31.3	21.8	33.8	32.5	37.1	17.3	10.7	32.5	18.6	42.8	33.7	11.5	38.2	48	35.7
2018-12-19	353	2	nan	26.7	21.4	19.1	15	21.2	20.3	13.2	30.2	31.7	14.4	24	29.2	28.9	23.7	31	31	12.1	24.3	17	30.7	18.7	35.2	32.9	22.3	30.4	31.5	22.3	34.1	32.5	37.7	17.9	7	32.8	28.5	42.5	34.2	11.6	38.2	47.7	35.7
2018-12-19	353	Avg	0-15cm																																									0
2018-12-19	353	Avg	15-30cm																																									0
2018-12-19	353	Avg	30-45cm																																									0
2018-12-19	353	Avg	45-60cm																																									0

mode = both
Moisture Point Probes VR
Array ( [0] => Solar_Panels_1 [1] => Flux_Tower_1 [2] => Gate_1 [3] => Biomass_Cage_1 [4] => Solar_Panels_2 [5] => Flux_Tower_2 [6] => Gate_2 [7] => Biomass_Cage_2 [8] => Solar_Panels_3 [9] => Flux_Tower_3 [10] => Gate_3 [11] => Biomass_Cage_3 [12] => Solar_Panels_4 [13] => Flux_Tower_4 [14] => Gate_4 [15] => Biomass_Cage_4 )

0000

Date	DOY	Rep	Depth	Solar_Panels_1	Flux_Tower_1	Gate_1	Biomass_Cage_1	Solar_Panels_2	Flux_Tower_2	Gate_2	Biomass_Cage_2	Solar_Panels_3	Flux_Tower_3	Gate_3	Biomass_Cage_3	Solar_Panels_4	Flux_Tower_4	Gate_4	Biomass_Cage_4	Spacial Count
2018-12-19	353	0	nan	28.2	10.6	26.4	15.6	28	35.6	23.7	21.6	31.5	25.7	24.6	32.1	43.7	21.9	34	32.8
2018-12-19	353	1	nan	28.5	13.2	26.4	15	28	37.4	23.4	22.2	31.5	27.1	24.6	32.1	43.1	20.5	34.5	32.8
2018-12-19	353	2	nan	28.5	6.6		15	27.4	38.1		21.6	31	27.6		31.8	42.5	20.2		32.5
2018-12-19	353	Avg	0-15cm																	0
2018-12-19	353	Avg	15-30cm																	0
2018-12-19	353	Avg	30-45cm																	0
2018-12-19	353	Avg	45-60cm																	0
