Field Notes

<--2006-11-19 11:00:00 | 2006-12-07 09:40:00-->
Phenocam link: Searching...

Tonzi: 2006-11-29 00:00:00 (DOY 333)
Author: Ted Hehn
Others:

Weather Cool & clear grass beginning to grow. Mr Tonzi said there was a frost event.

Trip Purpose General site visit, install RRR & automate data acquisition/file renaming on 2 data loggers

Tonzi Ranch:

29Nov06
Install Radiobot Radiation Railroad and log raw 1Hz data.

Attach RS232 cable to Snyders surface renewal data logger and attempt to communicate with logger. Failure. 100 foot RS232 cable has discontinuity in 2 of 10 conductors. Cut cable in half and continuity failure resides only on one half. Use one with continuity by soldering on 9 pin Sub D connector and cable now functions. However, the Usb-RS232 adapter I brought does not function.

30Nov06

Reconnect 2 auxiliary solar panels into floor power system

Automate data acquisition from SapFlow logger but again RS232 – USB adapter failure. This logger is named CR10X12.

This logger is showing many –6999 indicating open circuits on several channels.

Tower 14:45 zero and span LI800 on tower CO2 profile system

Field Data

No tank data

No TZ Well data found

No TZ Moisture Point data found

No VR Moisture Point data found

No TZ grass heigth found

No VR grass heigth found

No TZ Tree DBH found

No water potential data found

No TZ Grass Biomass data found

No TZ OakLeaves Biomass data found

No TZ PineNeedles Biomass data found
