Vaira: 2018-05-11 09:00:00 (DOY 131)
Author: Joe Verfaillie
Others: Siyan

Summary: Lots of flowers, problems with new CF cards from phenocam image collection.

Varia
2018-05-11

I arrived at about 9:00 with Siyan. It was clear sunny and warm with a strong breeze from the west. It was very windy across the central valley with lots of dust and debris in the air. The grasses have reached their peak and are starting to turn yellow. There are lots of flowers. The trees look heavy with leaves. There are no wet spots left on the road. We saw trucks and trailers headed out. Maybe moving cows to greener pastures already?

I collected all the data and then checked on the camera. It had only recorded a couple of days of data. I installed the new Ethernet switch and put in the new Verbatum CF card. I tested the script on the camera and kept getting and error about not being able to open a file. I thought there might be a problem with the camera that was blocking the file transfer. I had seen this once before when its disk was full, but I couldnâ€™t find anything wrong. So we went to Tonzi. At Tonzi I discovered that the CR1000s could not mount the Verbatum CF cards for whatever reason. We returned to Varia on our way home and reinstalled the SanDisk card.

Veg Height (cm): Tape measure from ground to top of plant
80, 43, 50, 86, 55, 46, 47, 48, 40, 34, 35, 30, 38, 23, 20, avg = 45, stdev = 18.28

Field Data

No tank data

Well Depth

Date	Location	Depth (feet)
2018-05-11	TZ_floor	18.8
2018-05-11	TZ_road	27.9
2018-05-11	TZ_tower	22.9

mode = both
Moisture Point Probes TZ
Array ( [0] => Tower_1 [1] => Floor_South_1 [2] => Floor_East_1 [3] => Floor_West_1 [4] => Soil_Transect_4_1 [5] => Soil_Transect_3_1 [6] => Soil_Transect_2_1 [7] => Soil_Transect_1_1 [8] => SoilCO2_West_A_1 [9] => SoilCO2_West_B_1 [10] => SoilCO2_West_C_1 [11] => Tower_2 [12] => Floor_South_2 [13] => Floor_East_2 [14] => Floor_West_2 [15] => Soil_Transect_4_2 [16] => Soil_Transect_3_2 [17] => Soil_Transect_2_2 [18] => Soil_Transect_1_2 [19] => SoilCO2_West_A_2 [20] => SoilCO2_West_B_2 [21] => SoilCO2_West_C_2 [22] => Tower_3 [23] => Floor_South_3 [24] => Floor_East_3 [25] => Floor_West_3 [26] => Soil_Transect_4_3 [27] => Soil_Transect_3_3 [28] => Soil_Transect_2_3 [29] => Soil_Transect_1_3 [30] => SoilCO2_West_A_3 [31] => SoilCO2_West_B_3 [32] => SoilCO2_West_C_3 [33] => Tower_4 [34] => Floor_South_4 [35] => Floor_East_4 [36] => Floor_West_4 [37] => Soil_Transect_4_4 [38] => Soil_Transect_3_4 [39] => Soil_Transect_2_4 [40] => Soil_Transect_1_4 [41] => SoilCO2_West_A_4 [42] => SoilCO2_West_B_4 [43] => SoilCO2_West_C_4 )

0000

Date	DOY	Rep	Depth	Tower_1	Floor_South_1	Floor_East_1	Floor_West_1	Soil_Transect_4_1	Soil_Transect_3_1	Soil_Transect_2_1	Soil_Transect_1_1	SoilCO2_West_A_1	SoilCO2_West_B_1	SoilCO2_West_C_1	Tower_2	Floor_South_2	Floor_East_2	Floor_West_2	Soil_Transect_4_2	Soil_Transect_3_2	Soil_Transect_2_2	Soil_Transect_1_2	SoilCO2_West_A_2	SoilCO2_West_B_2	SoilCO2_West_C_2	Tower_3	Floor_South_3	Floor_East_3	Floor_West_3	Soil_Transect_4_3	Soil_Transect_3_3	Soil_Transect_2_3	Soil_Transect_1_3	SoilCO2_West_A_3	SoilCO2_West_B_3	SoilCO2_West_C_3	Tower_4	Floor_South_4	Floor_East_4	Floor_West_4	Soil_Transect_4_4	Soil_Transect_3_4	Soil_Transect_2_4	Soil_Transect_1_4	SoilCO2_West_A_4	SoilCO2_West_B_4	SoilCO2_West_C_4	Spacial Count
2018-05-11	131	0	nan	9.4	2.2	13.5	11.1	7.1	6.2	7.4	3.6	8.6	10.3	7.4	17	14.2	17	11.5	10.6	18.5	19.1	6.3	13.3	5.7	17.3	20.7	22.6	39.6	20.7	13.1	20.1	24.3	20.9	24	22.6	24.3	32.2	34	39.4	34.5	18.5	29.7	42	18.8	35.4	34	37.1
2018-05-11	131	1	nan	9.4	2.8	15	13.5	7.4	6.2	8	3.6	13	9.4	7.1	16.4	13.6	17.8	11.5	10.3	19.4	18.8	6	13	5.7	17.6	19.5	22.6	25.1	19.8	13.7	20.1	23.1	20.9	24	22.3	23.5	32.2	33.7	43.1	31.1	17.9	29.1	41.4	18.2	35.1	34	36.8
2018-05-11	131	Avg	0-15cm																																													0
2018-05-11	131	Avg	15-30cm																																													0
2018-05-11	131	Avg	30-45cm																																													0
2018-05-11	131	Avg	45-60cm																																													0

mode = both
Moisture Point Probes VR
Array ( [0] => Solar_Panels_1 [1] => Flux_Tower_1 [2] => Gate_1 [3] => Biomass_Cage_1 [4] => Solar_Panels_2 [5] => Flux_Tower_2 [6] => Gate_2 [7] => Biomass_Cage_2 [8] => Solar_Panels_3 [9] => Flux_Tower_3 [10] => Gate_3 [11] => Biomass_Cage_3 [12] => Solar_Panels_4 [13] => Flux_Tower_4 [14] => Gate_4 [15] => Biomass_Cage_4 )

0000

Date	DOY	Rep	Depth	Solar_Panels_1	Flux_Tower_1	Gate_1	Biomass_Cage_1	Solar_Panels_2	Flux_Tower_2	Gate_2	Biomass_Cage_2	Solar_Panels_3	Flux_Tower_3	Gate_3	Biomass_Cage_3	Solar_Panels_4	Flux_Tower_4	Gate_4	Biomass_Cage_4	Spacial Count
2018-05-11	131	0	nan	5.8	2.1	3.6	1.8	10.9	13.8	11.2	9	17.6	10.1	10.9	18.1	30.5	21.9	12.5	21.6
2018-05-11	131	1	nan	7.4	0.3	5.6	2.1	10.9	16.7	10.2	7.5	17.6	12.9	10.9	18.7	31.4	18.5	10.2	20.5
2018-05-11	131	Avg	0-15cm																	0
2018-05-11	131	Avg	15-30cm																	0
2018-05-11	131	Avg	30-45cm																	0
2018-05-11	131	Avg	45-60cm																	0
