Field Notes

<--2019-08-06 10:30:00 | 2019-09-09 11:00:00-->
Other sites visited today: Tonzi | Tonzi
Phenocam link: Searching...

Vaira: 2019-08-22 10:30:00 (DOY 234)
Author: Joe Verfaillie
Others: Siyan

Summary: 7500 swapped, standard data collection, went to the pond.

Vaira
2019-08-22

Siyan and I arrived at about 10:30. It was clear and not with a nice breeze. The ground and grass are very crispy. The water hole is almost dry with just some mud puddle at the bottom. The stream from the pond is dry where is crosses the road.

Standard data collection. I swapped the 7500:
sn 75H-2668 off: 417.0ppm CO2, 656.1mmol/m3 H2O, 30.1C, 98.9kPa, 97.7SS
sn 0418 on: 418.7ppm CO2, 648.5mmol/m3 H2O, 30.6C, 98.9kPa, 95.2SS

Siyan did soil moisture, measured the well and cleaned the radiometers.

The pond level was 15.28ft

Field Data

No tank data

Well Depth

Date	Location	Depth (feet)
2019-08-22	TZ_floor	22.9
2019-08-22	TZ_tower	28
2019-08-22	TZ_road	32.1
2019-08-22	VR_well	56.1
2019-08-22	VR_pond	15.28

mode = both
Moisture Point Probes TZ
Array ( [0] => Tower_1 [1] => Floor_South_1 [2] => Floor_West_1 [3] => Soil_Transect_4_1 [4] => Soil_Transect_3_1 [5] => Soil_Transect_2_1 [6] => Soil_Transect_1_1 [7] => SoilCO2_West_A_1 [8] => SoilCO2_West_B_1 [9] => SoilCO2_West_C_1 [10] => Tower_2 [11] => Floor_South_2 [12] => Floor_West_2 [13] => Soil_Transect_4_2 [14] => Soil_Transect_3_2 [15] => Soil_Transect_2_2 [16] => Soil_Transect_1_2 [17] => SoilCO2_West_A_2 [18] => SoilCO2_West_C_2 [19] => Tower_3 [20] => Floor_South_3 [21] => Soil_Transect_4_3 [22] => Soil_Transect_3_3 [23] => Soil_Transect_2_3 [24] => Soil_Transect_1_3 [25] => SoilCO2_West_A_3 [26] => SoilCO2_West_B_3 [27] => SoilCO2_West_C_3 [28] => Tower_4 [29] => Soil_Transect_4_4 [30] => Soil_Transect_3_4 [31] => Soil_Transect_2_4 [32] => Soil_Transect_1_4 [33] => SoilCO2_West_A_4 [34] => SoilCO2_West_B_4 [35] => SoilCO2_West_C_4 [36] => SoilCO2_West_B_2 )

0000

Date	DOY	Rep	Depth	Tower_1	Floor_South_1	Floor_West_1	Soil_Transect_4_1	Soil_Transect_3_1	Soil_Transect_2_1	Soil_Transect_1_1	SoilCO2_West_A_1	SoilCO2_West_B_1	SoilCO2_West_C_1	Tower_2	Floor_South_2	Floor_West_2	Soil_Transect_4_2	Soil_Transect_3_2	Soil_Transect_2_2	Soil_Transect_1_2	SoilCO2_West_A_2	SoilCO2_West_C_2	Tower_3	Floor_South_3	Soil_Transect_4_3	Soil_Transect_3_3	Soil_Transect_2_3	Soil_Transect_1_3	SoilCO2_West_A_3	SoilCO2_West_B_3	SoilCO2_West_C_3	Tower_4	Soil_Transect_4_4	Soil_Transect_3_4	Soil_Transect_2_4	Soil_Transect_1_4	SoilCO2_West_A_4	SoilCO2_West_B_4	SoilCO2_West_C_4	SoilCO2_West_B_2	Spacial Count
2019-08-22	234	0	nan	3.9	1	3.3	3.1	1	1.5	0.1	5	5.9	12.8	11.5	5.7	7.2	7.5	14.5	13	5.4	7.2	12.1	14	20.1	9.8	16.5	17.9	13.7	16.5	-5.9	13.7	18.8	12.2	19.9	27.4	12.2	16.8	20.5	27.1
2019-08-22	234	1	nan	3.6	1	1.5	3.7	2.1	0.7	0.3	4.2	5	13.4	12.1	5.7	8.4	7.8	13.9	13.9	4.8	7.2	12.1	15.4	21.2	10.1	16.5	17.6	14.3	15	15.9	13.4	16.8	11.3	20.5	23.4	12.8	17.6	20.8	25.6	0.3
2019-08-22	234	Avg	0-15cm																																						0
2019-08-22	234	Avg	15-30cm																																						0
2019-08-22	234	Avg	30-45cm																																						0
2019-08-22	234	Avg	45-60cm																																						0

mode = both
Moisture Point Probes VR
Array ( [0] => Solar_Panels_1 [1] => Flux_Tower_1 [2] => Biomass_Cage_1 [3] => Solar_Panels_2 [4] => Flux_Tower_2 [5] => Biomass_Cage_2 [6] => Solar_Panels_3 [7] => Flux_Tower_3 [8] => Biomass_Cage_3 [9] => Solar_Panels_4 [10] => Flux_Tower_4 [11] => Biomass_Cage_4 )

0000

Date	DOY	Rep	Depth	Solar_Panels_1	Flux_Tower_1	Biomass_Cage_1	Solar_Panels_2	Flux_Tower_2	Biomass_Cage_2	Solar_Panels_3	Flux_Tower_3	Biomass_Cage_3	Solar_Panels_4	Flux_Tower_4	Biomass_Cage_4	Spacial Count
2019-08-22	234	0	nan	2.1	0.6	0.6	11.5	11.8	6.3	16.5	7.8	17.3	30.8	17.6	21.1
2019-08-22	234	1	nan	1.5	0.1	0.6	11.2	11.5	6.9	16.5	8.1	17.6	31.1	17.3	21
2019-08-22	234	Avg	0-15cm													0
2019-08-22	234	Avg	15-30cm													0
2019-08-22	234	Avg	30-45cm													0
2019-08-22	234	Avg	45-60cm													0
