When: Date: 5/28/2006 , Day: 147 , Watch Time: 10:00am .
Where: Tonzi/Vaira Ranch
Who: Siyan
Weather: clear, nice breezle
Phenology

• >70% grass at Vaira turned to yellow, and 30% grass remained green.
• Broad leaf herbs was blooming, yellow followers. Most of tall grass started to seed and die. Broad leaf herbs were green.

Summary

1. check and download data at Tower, Floor, and Vaira. All is well.
2. Spectrum measurement was taken. Take off the level on one side to level the other side.
3. collected grass sample for LAI and dry materials in Tower and Vaira, oak leaves and branches for LAI and N
4. measure soil moisture and dendrometer

Vaira_Grass Site

1. Fence and gate power: >12 v.
2. Panel and Batteries: 13.7 v; 12.0 amps; 2.2 amps.
3. Reading from Gillsonic screen before downloading data. (The value of H₂O and CO₂ should be in the range of 0 – 5 v.)

Time	9-51-20
Path/File name	D:\Data\V06_ 147 .flx D:\Data\VR06 1470930 .raw
	mean	std		mean	std
w	-0.80	0.336	Ts	18.21	1.589
u	1.24	0.840	H2O	2.362	0.111
v	0.78	0.705	CO2	1.952	0.001

1. downloading data
2. check the fans of air temp. and relative humidity sensors at Vaira. Good.
3. Check CR23X with two multiplexers: BUSY WITH COM
4. Check levels of Radiation sensors, clear up surfaces.
5. Closed gate and set up fence.

Tonzi_Tower Site

1. Fence and gate power: 12 v.
2. Panel and Batteries: 14.1 v; 0.0 amps; 5.6 amps.
3. Reading from Gillsonic screen before downloading data. (The value of H₂O and CO₂ should be in the range of 0 – 5 v.)

Time	10:43:57
Path/File name	D:\Data\T06_ 138 .flx D:\Data\TW061381000 .raw
	mean	std		mean	std
w	0.16	0.603	Ts	21.08	0.67
u	1.14	0.505	H2O	1.707	0.063
v	0.25	0.37	CO2	1.770	0.031

1. downloading data !!!! D120, be careful bad naming in flux data. Filenames need to be changed before processing.
2. check the fans of air temp. and relative humidity sensors on the tower and the floor. Good.
3. Check calibration cylinders;

CO₂ 2000 psig; flow 20 psi.
N₂ 2000 psig; flow 15 psi.
7. pump of CO2 profile system sounds OK.
8. close gate and set up fence.
Toniz_Floor Site

1. Fence and gate power: >12 v.
2. Panel and Batteries: 13.7 v; 8.8 amps; 1.9 amps.
3. Reading from Gillsonic screen before downloading data. (The value of H₂O and CO₂ should be in the range of 0 – 5 v.)

Time	11-27-10
Path/File name	D:\Data\F06_ .flx D:\Data\FL06 .raw
	mean	std		mean	std
w	0.04	0.274	Ts	20.52	1.05
u	0.07	0.304	H2O	2.26	0.13
v	0.35	0.354	CO2	1.554	0.049

downloading data

1. Soil CO₂ profile

Reading from datalogger

Panel temp		28.8
Battery voltage		13.4
CO2E_1	911	TCE_1	32	CO2W_1	761	TCW_1	19
CO2E_2	1118	TCE_2	34	CO2W_2	1286	TCW_2	17
CO2E_3	1701	TCE_3	24	CO2W_3	1991	TCW_3	17
CO2E_4	2143	TCE_4	20	CO2W_4	2159	TCW_4	17

Reading from panels of analyzers

depth	Open	order	depth	Tree	order
2cm (1%)	1840	1	2cm (1%)	930	1
4cm	2260	2	4cm	4330	4
8cm	3430	3	8cm	2510	2
16cm	4300	4	16cm	0.79%	3

1. Close gate and set up fence.

tonzi	7931AFE	402165	574B4B	402FF3	574632	7A432E	7A3C6E	7A3B40	7A4AAA
5/28/2006	147
	SM
0-15	11.1	9.1	19.2	11.9	15.6	11.7	17.6	8.5	4.3
15-30	16.3	15.5	19.1	15.2	12.5	8.7	18.2	14.3	3.1
30-45	21.8	18.4	11.3	17.9	9.5	13.3	20.3	18.9	16.8
45-60	21.3	19.6	6.2	26.2	19.6	14.9	17.1	26.0	14.1
	A6D882B	A3D04E8	A6D72F5
0-15	12.8	17.9	7.4
15-30	18.7	10.5	17.0
30-45	29.5	20.9	16.5
45-60	27.3	26.4	16.3
vaira	57318a	7933dee
0-15	11.1	8.4
15-30	8.7	12.2
30-45	13.5	13.3
45-60	16.6	17.8

Tonzi
Dendrometer
Date	Day	Tag #	Reading (cm)
5/28/2006	147	71	22.5
		72	23.4
		77	Broken
		78	Broken
		79	23.5
		245	23.1
		248	24.6
		250	21.8
		255	22.8
		‌252‌	missing
		102	Broken
