Tonzi: 2004-11-01 11:08:00 (DOY 306)
Author: Ted Hehn
Others:

Summary: New Tower computer, calibrate LI-800 bad solenoid

When: Mon,Tue 1Nov04 JD-305
Where: Tonzi Ranch
Who: Ted Hehn
Weather cool and clear

Trip Purpose Zero/span LI800 - change sonic at tower & data download

Tonzi Ranch:
1Nov04 11:08 The VIA computer (Larry) is on. Gillsonic is displayed but traces show no movement. The date is 306 the time is 10:41:01.

Clean lenses on LI7500. Did not change water channel reading: 0.00

Install USB to RS232 adapters to interface to the LI800 and CR10x7.

Place CR10x on com1 with a surge suppressor. Place sonic and LI800 on Usb/RS232 adapters.

11:17 shut down gillsonic to run zero/span on LI800
428.7 ppm CO2 cyl# sa3583
nitrogen cyl# cc102170 with soda lime scrubber stack on output

LI800 shows 958 mBar and cell temp = 52.6
Sample stream temp = 48.65 sample cell = 44.38

Pressure controller shows 960 mBar

Solenoid #5 (calibration) on the CO2 profile system failed to open repeatedly and must be replaced.

Misc Notes
Buy another solenoid for co2 profile system

Field Data

No tank data

No TZ Well data found

No TZ Moisture Point data found

No VR Moisture Point data found

No TZ grass heigth found

No VR grass heigth found

No TZ Tree DBH found

No water potential data found

No TZ Grass Biomass data found

No TZ OakLeaves Biomass data found

No TZ PineNeedles Biomass data found
