Field Notes

<--2025-03-24 13:33:00 |
Other sites visited today: Hill Slough | Rush Ranch | Gilbert Tract
Phenocam link: Searching...

Mayberry: 2025-03-26 11:20:00 (DOY 85)
Author: Joe Verfaillie
Others:

Summary: Cut up old scaffolding, Reinstalled miniCH4, pulled weeds.

Mayberry
2025-03-26

I arrived at about 12:20. It was partly cloudy with a cool wind. The main levees have been mowed since I was here last and there are goats on the south side of Mayberry slough. Looks like a bunch of heavy machine work on the power lines to the east – maybe new towers. The wetland is mostly brown but new tules and cattails are peeking though.

I started trying the hand hack saw on the old scaffolding. It worked better than the battery powered skill saw. In about 30min I had one frame cut up into straight pieces. I took a break and did the other things before cutting up the second frame just before leaving. I left all the metal there for recycling another time.

At the tower I reinstalled minCH4 sn 38-576-25. I was reading continuously so I could see that it was working before I put in the water. I cable tied it to the northeast scaffolding foot again – hopefully better than previously. Then I set it to timed reading and set the start time about 20min in the future.

While I installed the miniCH4 I notice the cable for the water level was inside the clamp for the floating boom. I don’t think the cable was damaged or pinched but I opened the clamp, got the cable out and refastened the clamp.

I pulled the weeds out around the solar panels here too and put some moth balls in the solar charger box.

I left at about 14:00 PDT


0 photos found

Graphs display:
11 sets found

7 MB_flux graphs found

Explore the graph:Sonic Wind in a new window

Explore the graph:LI7700 mV signals in a new window

Explore the graph:Counts in a new window

Explore the graph:LI7700 CH4 from analog signal in a new window

Explore the graph:LI7500 CO2 and H2O in a new window

Explore the graph:LI7700 CH4 from digital signal in a new window

Explore the graph:CO2 in ppm in a new window

No data found for MB_met.
28 MB_tule graphs found

Explore the graph:MB Tule Tower: Open Water 2 (3/1/11-3/23/17) in a new window

Explore the graph:MB Tule Tower: Open Water 1 (3/1/11-2/21/13) in a new window

Explore the graph:MB Tule Tower: Tule Temps 2 & 3 (3/1/11-3/19/14) in a new window

Explore the graph:MB Tule Tower: Tule Temps 1 (3/1/11-3/19/14) in a new window

Explore the graph:Mayberry Tule Tower: Solar Radiation in a new window

Explore the graph:Mayberry Tule Tower: Disolved Oxygen in a new window

Explore the graph:Mayberry Tule Tower: IRT and Sensor Temp in a new window

Explore the graph:Mayberry Tule Tower: Volts and RH in a new window

Explore the graph:LED NDVI Sensor in a new window

Explore the graph:Water CO2 in a new window

Explore the graph:Water Pressure in a new window

Explore the graph:Fluorometer Data in a new window

Explore the graph:Mayberry pCO2 Profile in a new window

Explore the graph:Water Temperatures in a new window

Explore the graph:Air Temperatures in a new window

Explore the graph:Air Pressure in a new window

Explore the graph:4-Way Radiometer in a new window

Explore the graph:MB Tule Tower: Open Water 1 (2/21/13-3/19/14) in a new window

Explore the graph:MB Tule Tower: Tule Temps 1 (3/19/14-now) in a new window

Explore the graph:MB Tule Tower: Open Water 1 (3/19/14-now) in a new window

Explore the graph:MB Tule Tower: Tule Temps 2 & 3 (3/19/14-3/23/17) in a new window

Explore the graph:MB Tule Tower: Tule Temps 2 (3/23/17-now) in a new window

Explore the graph:MB Tule Tower: Tule Temps 3 (3/23/17-now) in a new window

Explore the graph:SRS NDVI Channels in a new window

Explore the graph:SRS NDVI in a new window

Explore the graph:Net Radiation in a new window

Explore the graph:Conductivity in a new window

Explore the graph:Soil electrical conductivity in a new window

Can't check MBWPEESWGT_mixed
1 MB_cam graphs found

Explore the graph:Mayberry Autocam GCC in a new window

Can't check MBEEWPSWEPGT_cam
Can't check SIMBTWEE_met
No data found for MB_minidot.
Can't check MBSWEEWPBCBA
No data found for MB_processed.
Can't check MB_fd
1 MB_fd graphs found

Explore the graph:Water Forced Diffusion CO2 Flux in a new window
